PCL Air Technology Nexus Nitrogen Generator





NEXUS Nitrogen Generator and Built-in Digital Multi-head Tire Inflator Range

  Assembled, tested and calibrated in Sheffield, UK

  Nexus Nitrogen Generator   Combining the latest in high performance Nitrogen generaor with leading automatic inflation technology where individual pressures can be set for front and Nitrogen inflation from small passenger cars to large commercial vehicle and OTR tires in very demanding environments.





KEY PRODUCT BENEFITS

  • Revenue generation for Tire Service Providers
  • Both Nitrogen fill and Air to Nitrogen conversion service (purge) for up to 4 tires simultaneously
  • 4 separate digital inflator heads allow for setting different pressures for front and rear tires – speeds up vehicle turnaround and productivity for the volume tire bay
  • Low life time costs - with high grade filtration and high performance components
  • Guaranteed accuracy and robustness with ceramic pressure sensor
  • Models available for every inflation application - Car, Van, Truck & OTR tires




KEY PRODUCT FEATURES

  • Bigger filtration systems for super-fast Nitrogen delivery
  • New improved valves and fittings
  • Mobile with 90mm castors for improved flexibility and positioning options
  • External Nitrogen purity check point
  • Internal tanks meet CE standards
  • Easy to operate and quick installation
  • External Nitrogen tank contents gauge
  • Electronic preset tire inflation with auto-start and auto shut-off inflation
  • Automatic fl at tire detection
  • 1 purge inflation cycle from fl at 2 purge inflation cycle as standard
  • Ceramic sensor - accuracy up to ± 0.5% of full scale reading
  • Fully tested and calibrated with certificate supplied
  • Available in single phase supply 120v or 230v options







    In the 90-day static laboratory test, the inflation pressure loss for new tyres inflated with Nitrogen was approximately two-thirds of the loss rate of new tires inflated with air1







MAXIMUM APPLICATION

PART NUMBER

DESCRIPTION

MINIMUM
COMPRESSOR SUPPLY

MAXIMUM
FLOW RATE

Maximum Application

NEX2I(A)02/MQ

NEXUS N2 Generator &
multi-head inflator Range

368l/min (13CFM)
@ 10 BAR (145psi)
supply

70l/min
(2.5CFM)

NEX6I(A)02/MQ

NEXUS N6 Generator &
multi-head inflator Range

538l/min (19CFM)
@ 10 BAR (145psi)
supply

200l/min
(7CFM)

NEXMI(A)/MQ

NEXUS Membrane Generator
& multi-head inflator Range

1523l/min (54CFM)
@ 12 BAR (174psi)
supply

580l/min
(20CFM)









  Download Flyer

  Nitrogen Generator 1








NEXUS Nitrogen Generator & Built-in Digital Tire Inflator Range

  Combining the latest in high performance Nitrogen generation with leading automatic inflation technology where four tires can be inflated simultaneously. This new range of equipment is designed to cover every application of Nitrogen Inflation from small passenger cars to large commercial vehicle and OTR tires in very demanding environments.

  PCL Nitorgen Generator



KEY PRODUCT BENEFITS

  • Revenue generation for Tire Service Providers
  • Both Nitrogen fill and Air to Nitrogen conversion service (purge) for up to 4 tires simultaneously
  • 4 outputs and four hoses supplied as standard for automatic conversion of up to 4 tires from air to Nitrogen increases productivity
  • Low life time costs - with high grade filtration and high performance components
  • Guaranteed accuracy and robustness with ceramic pressure sensor
  • Models available for every inflation application - Car, Van, Truck & OTR tires







KEY PRODUCT FEATURES

  • Bigger filtration systems for super-fast Nitrogen delivery
  • New improved valves and fittings
  • Mobile with 90mm castors for improved flexibility and positioning options
  • External Nitrogen purity check point
  • Internal tanks meet CE standards
  • Easy to operate and quick installation
  • External Nitrogen tank contents gauge
  • Electronic preset tire inflation with auto-start and auto shut-off inflation
  • Automatic fl at tire detection
  • 1 purge inflation cycle from fl at 2 purge inflation cycle as standard
  • Ceramic sensor - accuracy up to ± 0.5% of full scale reading
  • Fully tested and calibrated with certificate supplied
  • Available in single phase supply 120v or 230v options


















MAXIMUM APPLICATION

PART NUMBER

DESCRIPTION

MINIMUM
COMPRESSOR SUPPLY

MAXIMUM
FLOW RATE

Maximum Application

NEX2I(A)02

NEXUS N2 Generator/inflator Range

368l/min (13CFM)
@ 10 BAR (145psi)
supply

70l/min
(2.5CFM)

NEX6I(A)02

NEXUS N6 Generator/
inflator Range

538l/min (19CFM)
@ 10 BAR (145psi)
supply

200l/min
(7CFM)

NEXMI(A)

NEXUS Membrane
Generator/inflator Range

1523l/min (54CFM)
@ 12 BAR (174psi)
supply

580l/min
(20CFM)









Download Flyer



  Nitrogen Generator 2








NEXUS Nitrogen Generator Only Range

  Assembled, tested and calibrated in Sheffield, UK

  Nexus Nitrogen Generator   The latest in high performance Nitrogen generation. The PCL NEXUS series generators allow the operator to use existing equipment to deliver high purity Nitrogen to the desired application. This new range of Nitrogen generators can cover every application of Nitrogen inflation from small passenger cars to large commercial vehicle and OTR tires in very demanding environments.





KEY PRODUCT BENEFITS

  • Revenue generation for Tire Service Providers
  • Cost effective Nitrogen delivery with very low maintenance
  • Low life time costs - with high grade filtration and high performance components
  • Guaranteed tank pressure accuracy and robustness
  • Models available for every inflation application - Car, Van, Truck & OTR tires




KEY PRODUCT FEATURES

  • Bigger filtration systems for super-fast Nitrogen delivery
  • New improved valves and fittings
  • Mobile with 90mm castors for improved flexibility and positioning options
  • External Nitrogen purity check point
  • Internal tanks meet CE standards
  • Easy to operate and quick installation
  • Digital Nitrogen tank contents gauge
  • Ceramic sensor - accuracy up to ± 0.5% of full scale reading
  • Fully tested and calibrated with certificate supplied
  • Available in single phase supply 120v or 230v options





    NASA says the space shuttle tires don’t explode in space because they’re filled with Nitrogen, which has more stability at different altitudes and temperatures than regular air6








MAXIMUM APPLICATION

PART NUMBER

DESCRIPTION

MINIMUM
COMPRESSOR SUPPLY

MAXIMUM
FLOW RATE

Maximum Application

NEX2G(A)02

NEXUS N2 Generator Only
Range

368l/min (13CFM)
@ 10 BAR (145psi)
supply

70l/min
(2.5CFM)

NEX6G(A)02

NEXUS N6 Generator Only
Range

538l/min (19CFM)
@ 10 BAR (145psi)
supply

200l/min
(7CFM)

NEXMG(A)02

NEXUS Membrane Generator
Only Range

1523l/min (54CFM)
@ 12 BAR (174psi)
supply

580l/min
(20CFM)











Download Flyer



  Nitrogen Generator Pic3









NEXUS Nitrogen Generator Only Range

  The most innovative digital Nitrogen inflation device on the market. The NEXUS Compact is suitable for all types of Nitrogen tire inflation applications where space and weight are at a premium. Small enough to fit into mobile tire service vehicles, yet fast enough to inflate the biggest of commercial tires. Models available for workshops, forecourts and vehicle mounted applications.

  PCL Nexus Nitrogen Generator



KEY PRODUCT BENEFITS

  • Revenue generation for Tire Service Providers
  • Both Nitrogen fill and Air to Nitrogen conversion service for up to 4 tires at once
  • Compact footprint and lightweight design allow for us in a number of applications
  • Low life time costs - with high grade membrane Nitrogen production
  • Guaranteed inflation accuracy and robustness with ceramic pressure sensor
  • Models available for inflating large OTR tires from mobile service trucks







KEY PRODUCT FEATURES

  • High speed digital Nitrogen inflation up to and including large commercial tires
  • High purity delivery, up to 99% purity (depending on speed requirements)
  • Brand new space-saving membrane filtration device and cabinet design
  • Total unit weight only 30kg, significantly lighter than any other Nitrogen generator and inflator in the NEXUS range Cab can be fitted with brackets for attaching to the inside or
  • outside of mobile tire service vehicles
  • Weatherproof - conforms to electricity standard IP66
  • Various supply voltages available in single phase supply (12v, 24v, 120v or 230v)
  • Internal tanks meet CE standards
  • Easy to operate - plug and play
  • Designed for 1 OTR tire, 2 HGV tires or up to 4 passenger car tires at once
  • Ceramic sensor - accuracy up to ±0.5% of full scale reading
  • Calibrated with certificate supplied




    Assembled, tested and calibrated in Sheffield, UK

    All the tests conducted clearly indicate that Nitrogen inflation in passenger car tires can improve passenger safety and tire life while improving the fuel economy of the vehicle4











MAXIMUM APPLICATION

PART NUMBER

DESCRIPTION

MINIMUM
COMPRESSOR SUPPLY

MAXIMUM
FLOW RATE

NEXCI(A)/W

NEXUS Compact Workshop
Nitrogen Generator & built-in inflator

980l/min (35CFM)
@ 11 BAR (160psi)
supply

300l/min
(10CFM)

NEXCI(A)/M

NEXUS Compact Vehicle
Mounted Nitrogen Generator
& built-in inflator

980l/min (35CFM)
@ 11 BAR (160psi)
supply

300l/min
(10CFM)

NEXCI(A)/F

NEXUS Compact Forecourt
Nitrogen Generator & built-in inflator

580l/min (20CFM)
@ 10 BAR (145psi)
supply

168l/min
(6CFM)











  Nexus Nitrogen Generator



  Download Flyer
