Tornado Scrubbers & Dryers |
|
|
|
|
|
|
MODELS |
|
|
|
|
|
|
|
|
|
|
|
BR 13/1 MW Family
Multi-Surface Scrubber |
|
BD 28/20
Large Walk-Behind Scrubber |
|
|
|
|
|
|
|
|
|
BR 16/3
Compact Floor Scrubber |
|
BD 26/26
Walk-Behind Scrubber |
|
|
|
|
|
|
|
|
|
BD 14/4
Compact Cordless Scrubber |
|
BR 28/27 and BD 26/27
Ride-On Automatic Scrubbers |
|
|
|
|
|
|
|
|
|
BD 17/6
Compact Cordless Scrubber |
|
BR and BD 33/30
Ride-On Automatic Scrubbers |
|
|
|
|
|
|
|
|
|
EZ Floorkeeper®
20" and 24" Floor Scrubbers |
|
BR 40/66 and BD 40/66
Ride-On Automatic Scrubbers |
|
|
|
|
|
|
|
|
|
BR 18/11 and BD 20/11
Small Walk-Behind Scrubbers |
|
BD 32/26
Walk-Behind Automatic Scrubber |
|
|
|
|
|
|
|
|
|
BR 22/14 and BD 26/14
Medium Walk-Behind |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BR 13/1 MW Family
Multi-Surface Scrubber |
|
|
|
|
|
|
|
|
|
|
|
 |
|
Features: |
|
|
|
- Excellent results on hard floor coverings including vinyl tile, brick, slate, mosaic, granite, marble and rubber floors.
- BR 13/1 BAT offers cordless operation with sealed, maintenance free Lithium-Iron Phosphate batteries.
- Can be used on escalators, commercial-grade carpeting and entrance matting.
- Particularly effective for tile and grout cleaning and non-slip safety floors.
- Perfect for eco-friendly encapsulation carpet cleaning for commercial grade carpets and entrance mats.
- Choice of brushes for normal maintenance or intensive scrubbing. Cylindrical brushes “lift” and revitalize carpet fibers while low-moisture solution atomization minimizes moisture, allergens and bacteria in carpets.
- Side brushes are available and facilitate edge-cleaning right into hard-to-reach corners.
- Perfect for hotels, hospitals, restaurants, restrooms, schools, airports, and retail sales floors.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview |
|
|
|
BR 13/1 MW Family
Low-Moisture, Multi-Purpose Scrubbers for Hard and Soft Floors
The BR 131/1 MW Family is easier on the indoor environment and makes cleaning so simple, it is actually enjoyable. In-house facility managers, building engineers, housekeepers and BSCs will appreciate the BR 13/1 MW’s superior flexibility, advanced productivity and reduced environmental impact. Now available with lithium-iron batteries, the BR 13/1 MW BAT cleans longer, recharges faster and reduces energy consumption. Where high quality floor cleaning performance, ease of use and durability are called for, the BR 13/1 MW Family is the most versatile and effective answer for any hard or soft floor surface. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure |
|
|
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
Model |
BR 13/1 MW |
BR 13/1 BAT |
Catalog Number |
99410 |
99412 |
Cleaning Path |
13 in / 33 cm |
13 in / 33 cm |
Productivity per Hour |
3775 sq. ft. / hr. |
3775 sq. ft. / hr. |
Solution / Recovery Tank |
1 gal./4 lit. |
1 gal./4 lit. |
Sound Level |
69 dBA |
66 dbA |
Brush Motor |
1 hp / 600 W |
.4 hp / 300 W |
Power |
650 rpm |
400 rpm |
Weight |
55 lbs. |
49 lbs. |
Dimensions (L x W x H) |
15 in. x 17 in. x 44 in. |
15 in. x 17 in. x 44 in. |
Tank Construction |
Polyethylene |
Polyethylene |
Brush Width |
12"/30 cm |
12"/30 cm |
Brush Type |
Counter-rotating cylindrical (x2) |
Counter-rotating cylindrical (x2) |
Charger |
NA |
On-board |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BR 16/3
Compact Floor Scrubber |
|
|
|
|
 |
|
Features: |
|
|
|
- Removable two-chamber tank system
- Adjustable brush pressure
- Cylindrical brushes spin at 660 RPMs
- Large, removable transport wheels
- Both the solution and recovery tank are removable for quick and easy disposal of solution
- With a simple change of the brushes you can strip hard floors easily!
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview |
|
|
|
BR 16/3
Powerful, automatic floor scrubbing in a compact package.
The BR 16/3 puts the power of automatic scrubbing in a compact package ready for virtually any hard floor surface. This corded electric unit, operates in forward and reverse with a 16” scrubbing path at 1,100 RPMs. Cleaning approximately 4,306 square feet per hour, your small and congested spaces are clean, dry, healthy and ready for use in no time. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure |
|
|
|
|
|
|
|
|
|
Specirfications: |
|
|
|
|
Model |
BR 16/3 |
Catalog Number |
99406 |
Cleaning Path |
16 in. |
Productivity per Hour |
3200 sq. ft. / hr. |
Solution Tank |
3 gal / 10 l |
Recovery Tank |
3 gal / 10 l |
Sound Level |
71 dB |
Brush Type |
Cylindrical |
Brush Width |
16 in / 400 mm |
Brush RPM |
660 RPM |
Vacuum Motor |
0.67 hp |
Brush Motor |
1.5 hp |
Weight |
67 lbs. |
Dimensions (L x W x H) (in. / mm) |
15 in. x 17 in. x 44 in. / 520 mm x 470 mm x 380 mm |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BD 14/4
Compact Cordless Scrubber |
|
Features: |
|
|
 |
|
- Compact Automatic Scrubbing
- Eco-friendly AGM battery operated unit
- Incredible water recovery even on 180 degree turns
- Parabolic squeegee
- On-board battery charger
- 14" Cleaning path
- Clean 11,300 square feet per hour
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BD 14/4
Compact Cordless Automatic Scrubber Perfect for small spaces!
Designed to scrub hard-to-clean areas where a traditional mop and bucket are used, the eco-friendly battery operated BD 14/4 floor scrubber from Tornado® is compact, powerful, versatile and perfect for small or confined spaces. Cleaning approximately 11,300 square feet in an hour, your small and congested spaces are clean, dry, healthy and safe in no time. Say goodbye to corded electric units that can cause trips and falls. The BD 14/4’s eco-friendly, maintenance-free AGM battery eliminates the danger of a power cord and periodic maintenance. What’s more, the ergonomic handle minimizes worker fatigue and injuries. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
Model |
BD 14/4 |
Catalog Number |
99414 |
Cleaning Path |
14 in. |
Productivity per Hour |
13,342 sq. ft. per hour |
Capacity (Solution / Recovery Tank) |
3.5 gal / 4 gal. |
Sound Level |
69 dB |
Vac Motor |
0.8 hp |
Power |
24V battery |
Weight |
132 lbs. (w/o batteries) |
Dimensions (L x W x H) |
38 in. x 15 in. x 36 in. |
Tank Construction |
Polyethylene |
Brush Width |
14" |
Brush Type |
Disc |
Brush RPM |
180 RPM |
Squeegee Width |
16" |
Brush Motor |
0.3 hp |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BD 17/6
Compact Cordless Scrubber |
|
Features: |
|
|
|
|
Compact Automatic Scrubbing
Eco-friendly AGM battery operated unit
Incredible water recovery even on 180 degree turns
Parabolic squeegee
On-board battery charger
17" Cleaning path
Clean 16,200 square feet per hour |
|
|
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BD 17/6
World Class Scrubber Delivering Versatility and Enhanced Productivity
The battery-operated BD 17/6 Compact Scrubber is perfect for small-to-medium sized spaces, or hard-to-clean areas underneath counters where a mop is traditionally used. Offering a six gallon recovery tank and an integrated parabolic squeegee for immediate solution pick-up, this machine makes your most difficult cleaning tasks no problem at all! |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
Model |
BD 17/6 |
Catalog Number |
99617 |
Cleaning Path |
17 in. |
Productivity per Hour |
16,200 sq. ft. per hour |
Capacity (Solution / Recovery Tank) |
6 gal / 6 gal. |
Sound Level |
69 dB |
Vac Motor |
340 W / 14 amp |
Power Cord Length |
Cordless |
Power |
24V battery |
Weight |
191 lbs. (w/o batteries) |
Dimensions (L x W x H) |
31 in x 24 in x 21 in/793 mm x 603 mm x 518 mm |
Tank Construction |
Polyethylene |
Brush Width |
17" |
Brush Type |
Disc |
Brush RPM |
190 RPM |
Squeegee Width |
20" |
Brush Motor |
340 W / 14 amp |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EZ Floorkeeper®
20" and 24" Floor Scrubbers |
|
Features: |
|
|
 |
|
Certain units feature a traction drive
Best in class 1hp/200 rpm brush drive motor
3 stage vacuum motor
13 gallon recovery tank
Appropriate for commercial and healthcare applications as well as detail cleaning projects in industrial facilities |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
|
|
|
|
EZ Floorkeeper®
20" and 24" Floorkeepers®
Each of the units in Tornado's® EZ Series of floor scrubbers provide excellent scrubbing results on a wide range of hard floor surfaces including tile, linoleum, cement, epoxy and rubberized surfaces. In a single pass, the EZ Floorkeeper® lays down solution, scrubs and recovers dirty water leaving a clean, dry floor in its wake. Tornado® EZ scrubbers are used worldwide in retail stores, grocery chains, commercial and light industrial applications. The traction units are state of the art featuring all digital controls for ease of use, service and programmability. Units ship complete with our uniquely designed "roll off and run" pallet and delivery system. Order today and begin improving your facility's appearance and labor savings as early as tomorrow!
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure: |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
|
|
|
|
|
Model |
20" EZ Brush Drive |
20" EZ TRACTION DRIVE |
24" EZ TRACTION DRIVE |
Catalog Number |
99105A & 99105B |
99125A & 99125B |
99130 |
Cleaning Path |
20 in. |
20 in. |
24 in. |
Waterlift |
71 in. |
1 in. |
1 in. |
CFM |
65 |
65 |
65 |
Capacity (Solution / Recovery Tank) |
13 gal. / 13 gal. |
13 gal. / 13 gal. |
13 gal. / 13 gal. |
Vac Motor |
.75 hp (3-stage) |
.75 hp (3-stage) |
.75 hp (3-stage) |
Weight |
151 lbs. (w/o batteries) |
166 lbs. (w/o batteries) |
172 lbs. (w/o batteries) |
Dimensions (L x W x H) |
49 in. x 22 in. x 37 in. |
49 in. x 22 in. x 37 in. |
53 in. x 28 in. x 37 in. |
Brush Width |
20" |
20" |
24" |
Brush RPM |
200 RPM |
200 RPM |
200 RPM |
Squeegee Width |
28" |
28" |
32" |
Brush Motor |
1.0 hp |
1.0 hp |
1.0 hp |
Brush/Pad Pressure |
67 lbs. |
65-85 lbs. |
72 lbs. |
Drive |
Brush Assist |
Traction Drive |
Traction Drive |
Forward Speed |
0 to 150 FPM |
0 to 200 FPM |
0 to 200 FPM |
Reverse Speed |
N/A |
150 FPM |
150 FPM |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BR 18/11 and BD 20/11
Small Walk-Behind Scrubbers |
|
Features: |
|
|
|
|
18” cleaning path on BR unit
20” cleaning path on BD unit
11 gallon solution tank
Simple operator interface
Exceptionally durable rotomolded polyethylene construction
Low-profile sight line
Whisper Quiet 67 dB
Eco-friendly, 100% non-spill battery available |
|
|
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BR 18/11 and BD 20/11
World Class Small Walk-Behind Auto-Scrubbers
Designed from the ground up with our customer's needs in mind, the BR 18/11 and BD 20/11 small walk-behind scrubbers from Tornado® are perfect for smaller spaces and are offered in your choice of a disc or cylindrical brush for hard floor scrubbing. These small scrubbers meet rigorous global user standards for durability and productivity, offering enhanced features, benefits and a sleek look that clearly outmatches the competition. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure |
|
|
|
|
|
|
|
|
|
Specifications |
|
|
|
|
Model |
BR 18/11 |
BD 20/11 |
Catalog Number |
99685 |
99680 |
Cleaning Path |
18 in. |
20 in. |
Productivity per Hour |
17,969 sq ft. per hr. |
18,830 sq. ft. per hr. |
Capacity (Solution / Recovery Tank) |
11 gal. / 12 gal. |
11 gal. / 12 gal. |
Sound Level |
66 dB |
66 dB |
Vac Motor |
0.6 hp |
0.6 hp |
Power |
24V battery |
24V battery |
Weight |
157 lbs. |
157 lbs. |
Dimensions (L x W x H) |
43 in. x 21 in. x 41 in. |
43 in. x 21 in. x 41 in. |
Tank Construction |
Polyethylene |
Polyethylene |
Brush Width |
18" |
20" |
Brush Type |
Cylindrical |
Disc |
Brush RPM |
1300 RPM |
350 RPM |
Brush Motor |
0.6 hp |
0.6 hp |
Brush/Pad Pressure |
50 lbs. |
50 lbs. |
Squeegee Width |
31" |
31" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BR 22/14 and BD 26/14
Medium Walk-Behind |
|
Features: |
|
|
 |
|
Medium walk-behind unit suited for schools, hotels, retail shops, restaurants, and hospitals
BD unit has a 26” cleaning path
BR unit has a 22” cleaning path
14 gallon solution tank
Simple operator interface
Whisper Quiet 67 dB
Eco-friendly, 100% non-spill battery available
Heavy-duty, four-sided, parabolic squeegee |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BR 22/14 and BD 26/14
World Class Medium Walk-Behind Auto-Scrubbers
Tornado's BR 22/14 and BD 26/14 medium walk behind scrubbers are designed for use in moderately spaced interiors, and deliver world class scrubbing performance, amazing durability, and environmental sustainability. With Tornado's world class medium walk-behind auto scrubbers, you'll get enhanced cleaning performance, drier floors and increased building and occupant safety. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure |
|
|
|
|
|
|
|
|
|
Specifcations: |
|
|
|
|
Model |
BR 22/14 |
BR 22/14T |
BD 26/14 |
Catalog Number |
99695 |
99695T |
99720 |
Cleaning Path |
22 in. |
22 in. |
26 in. |
Productivity per Hour |
20,552 sq.ft. per hr. |
22,000 sq. ft. per hr. |
29,225 sq.ft. per hr. |
Capacity (Solution / Recovery Tank) |
14 / 15 gal. |
14 / 15 gal. |
14 / 15 gal. |
Sound Level |
67 dB |
67 dB |
67 dB |
Vac Motor |
0.6 hp |
0.6 hp |
0.8 hp |
Power |
24V battery |
24V battery |
24V battery |
Weight |
223 lbs. |
223 lbs. |
244 lbs. |
Dimensions (L x W x H) |
50 in. x 24 in. x 42 in. |
50 in. x 24 in. x 42 in. |
53 in. x 28 in. x 42 in. |
Tank Construction |
Polyethylene |
Polyethylene |
Polyethylene |
Brush Width |
22" |
22" |
26" |
Brush Type |
Cylindrical |
Cylindrical |
Twin Disc |
Brush RPM |
1300 RPM |
1300 RPM |
345 RPM |
Brush Motor |
0.6 hp |
0.6 hp |
1.0 hp |
Brush/Pad Pressure |
79 lbs. |
79 lbs. |
110 lbs. max |
Squeegee Width |
33" |
33" |
33" |
Traction Drive |
No |
Yes |
Yes |
On-Board Charger |
No |
Yes |
No |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BD 28/20
Large Walk-Behind Scrubber |
|
Features: |
|
|
 |
|
Large walk-behind unit suited for grocery stores, large retail facilities, schools, industrial facilities and hospitals
28” cleaning path
20 gallon solution tank
Simple operator interface
Built-in safety feature avoids work-related accidents
Optional eco-friendly, 100% non-spill AGM battery available
Heavy-duty, four-sided, parabolic squeegee for extended blade life
Ergonomic handle design
Exceptionally durable rotomolded polyethylene construction
Stainless steel battery tray
Dual access to solution and recovery tanks |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BD 28/20
Large Walk-Behind Automatic Scrubber
Tornado’s BD 28/20 walk-behind scrubber offers world class scrubbing with a narrow profile and wide cleaning path. This unit is perfect for use in grocery stores, retail facilities, hospitals, and warehouses.The BD 28/20 lays down cleaning solution, scrubs, then vacuums away dirty solution, leaving floors clean and dry in just one pass, even around 180 degree turns. Clean over 29,493 square feet per hour while increasing your building’s occupant health and safety. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure: |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
Model |
BD 28/20 |
Catalog Number |
99728 |
Cleaning Width |
28 in / 685 mm |
Productivity per Hour |
29,493 sq. ft. per hr/2,740 m2 per hr |
Capacity (Solution / Recovery Tank) |
20 gal/75 l / 22 gal / 85 l |
Vac Motor |
570 Watts / 23.75 Amps |
Traction Motor |
300 Watts / 12.5 Amps |
Battery Power |
24V |
Weight |
320 lbs. / 145 kg (w/o batteries) |
Dimensions (L x W x H) |
59 in x 30 in x 41 in/1490 mm x 760 mm x 1045 mm |
Brush/Pad Diameter |
14"/355 mm (2 Brushes) |
Brush Type |
Disc |
Brush RPM |
160 |
Brush Motor |
700 Watts / 29 Amps |
Brush/Pad Pressure |
up to 110 lbs. / 50 kg |
Squeegee Width |
33 in / 835 mm |
Maximum Speed |
2.5 miles per hour/4 km per hour |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BD 26/26
Walk-Behind Scrubber |
|
Features: |
|
|
 |
|
- Large walk-behind unit suited for grocery stores, large retail facilities, schools, industrial facilities and hospitals
- 26” cleaning path
- 26 gallon solution tank
- 28 gallon recovery tank
- Simple operator interface
- Whisper Quiet 67 dB
- Tight turning radius for superior maneuverability
- Built-in safety feature avoids work-related accidents
- Optional eco-friendly, 100% non-spill AGM battery available
- Heavy-duty, four-sided, parabolic squeegee
- Ergonomic handle design
- Exceptionally durable roto-molded polyethylene construction
- Stainless steel battery tray
- Manual adjustment of brush pressure
- Dual access to solution and recovery tanks
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BD 26/26
Walk-Behind Automatic Scrubber Scrubber Delivering Superior Productivity, Durability and Improved Health
Tornado's BD 26/26 walk-behind scrubber offers world class scrubbing, a wide cleaning path and large capacity solution and recovery tanks. This unit is perfect for use in grocery stores, retail facilities, hospitals, and warehouses. The BD 26/26 lays down cleaning solution, scrubs, then vacuums away dirty solution, leaving floors clean and dry in just one pass, even around 180 degree turns. Clean over 32,300 square feet per hour while increasing your building's occupant health and safety. Rigorously tested in the field, the BD 26/26 walk-behind scrubber is constructed with a tough rotomold polyethylene body, ensuring years of maximum performance and reliability. Service down-time is significantly reduced with its wide-open clam shell design for fast and easy access to tanks, batteries and motor. For application flexibility and easy maintenance, there are no tools required when changing disc brushes. When it comes to longevity, Tornado's BD 26/26 walk-behind scrubber will outlast the competition, and comes standard with a 10 year warranty on the body and tanks for years of hassle-free use and reliability. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure: |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
Model |
BD 26/26 |
Catalog Number |
99726 |
Cleaning Path |
26 in. |
Productivity per Hour |
32,280 sq. ft. per hr. |
Capacity (Solution / Recovery Tank) |
26 gal / 28 gal. |
Sound Level |
67 dB |
Vac Motor |
0.8 hp |
Power |
24V battery |
Weight |
700 lbs. (w/o batteries) |
Dimensions (L x W x H) |
66 in. x 29 in. x 47 in. |
Tank Construction |
Polyethylene |
Brush Width |
13" (2 Brushes) |
Brush Type |
Disc |
Brush RPM |
190 RPM |
Brush Motor |
1.1 hp |
Brush/Pad Pressure |
up to 133 lbs. |
Squeegee Width |
39" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BR 28/27 and BD 26/27
Ride-On Automatic Scrubbers |
|
Features: |
|
|
 |
|
26" Cleaning Path
27 gal. Solution Tank
27 gal. Recovery Tank
Automatic operation control mode and squeegee retraction when in reverse
Steering radius of only 6 feet for maneuvering tight corners
Simple operator interface |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BR 28/27 and BD 26/27
Ride-On Auto-Scrubber Delivering Increased Productivity, Durability, Health and Safety
Maintain and renew hard floor surfaces faster than ever before with Tornado's BR 28/27 and BD 26/27 Ride-on Automatic Scrubbers. These units increase cleaning productivity in areas where walk-behind scrubbers were used in the past, thanks to their compact footprint and great maneuverability. The BR 28/27 and BD 26/27 are the perfect units for cleaning supermarkets, schools, health care, warehouses, and more! |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure: |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
Model |
BD 26/27 |
BR 28/27 |
Catalog Number |
99772 |
99775 |
Cleaning Path |
26 in. |
28 in. |
Productivity per Hour |
35,508 sq.ft. per hr. |
37,673 sq. ft. per hr. |
Capacity (Solution / Recovery Tank) |
27 gal. / 27 gal. |
27 gal. / 28 gal. |
Sound Level |
69 dB |
69 dB |
Vac Motor |
580 W |
580 W |
Power |
24V battery |
24V battery |
Weight |
573 lbs. (w/o batteries) |
578 lbs. (w/o batteries) |
Dimensions (L x W x H) |
62 in. x 28 in. x 52 in. |
62 in. x 31 in. x 52 in. |
Tank Construction |
Polyethylene |
Polyethylene |
Brush width |
26" |
28" |
Brush Type |
Disc |
Cylindrical |
Brush RPM |
190 RPM |
785 RPM |
Brush Motor |
650 W |
600 W (x2) |
Brush/Pad Pressure |
132 lbs. max |
320 lbs. max |
Squeegee Width |
39" |
38.5" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BR and BD 33/30
Ride-On Automatic Scrubbers |
|
Features: |
|
|
 |
|
BR unit has a 33” cleaning path
BR units come standard with a stainless steel pre-sweep function
BD unit has a 33” cleaning path
30 gallon solution tank
Automatic operation control mode and squeegee retraction when in reverse
Steering radius of only 6 feet for maneuvering tight corners
Simple operator interface |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BR and BD 33/30 World Class Ride-On Automatic Scrubbers Renew hard floor surfaces in large, unobstructed spaces faster than ever before.Tornado's ride-on automatic scrubbers increase cleaning productivity in areas including supermarkets, manufacturing plants, airports, exhibit halls and much more. For effortless operation, Tornado’s ride-on BR and BD 33/30 units offer an automatic mode which will start all necessary operations of the scrubber once it is turned on. This system also gradually starts all of the motors and constantly controls the operation parameters to guarantee longer run-time and reliability. When in reverse, this machine also includes an automatic squeegee retraction feature. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure: |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
Model |
BD 33/30 |
BR 33/30 |
Catalog Number |
99780 |
99785 |
Cleaning Path |
33 in. |
33 in. |
Productivity per Hour |
55,952 sq. ft. per hr. |
55,952 sq. ft. per hr. |
Capacity (Solution / Recovery Tank) |
30 / 32 gal. |
30 / 32 gal. |
Sound Level |
70 dB |
70 dB |
Vac Motor |
0.7 hp |
0.8 hp |
Power |
36V battery |
36V battery |
Weight |
690 lbs. |
739 lbs. |
Dimensions (L x W x H) |
65 in. x 35 in. x 67 in. |
65 in. x 36 in. x 51 in. |
Tank Construction |
Polyethylene |
Polyethylene |
Brush Width |
33" |
33" |
Brush Type |
Twin Disc |
Cylindrical |
Brush RPM |
162 RPM |
785 RPM |
Brush Motor |
1.5 hp |
0.9 hp |
Brush/Pad Pressure |
187 lbs. max |
176 lbs. max |
Squeegee Width |
45" |
45" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BR 40/66 and BD 40/66
Ride-On Automatic Scrubbers |
|
Features: |
|
|
 |
|
40 inch cleaning path
BR unit features a pre-sweep tray.
62 gallon solution tank
Automatic operation control mode and squeegee retraction when in reverse
Heavy-Duty industrial design allowing these units to tackle the toughest environments |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
BR 40/66 and BD 40/66
Ride-On Automatic Scrubber
Tornado’s new BD 40/66 and BR 40/66 ride-on scrubbers not only further extends our ride-on offering, but is designed to meet the toughest cleaning applications. Available in disc and cylindrical options, with 62 gallon solution tanks and heavy-duty body design these scrubbers have the features to solve your toughest cleaning challenges.The environmentally preferred BR 40/66 offer the latest modern enhancement—cylindrical brush technology. The use of cylindrical brush technology delivers low moisture cleaning design and deep scrubbing through concentrated brush speeds of 933 RPM—over six times higher than the speed of comparable rotary brush automatic scrubbers. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure: |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
Model |
BD 40/66 |
BR 40/66 |
Catalog Number |
99790 |
99795 |
Dimensions (L x W x H) |
80 in. x 41 in. x 77 in. |
80 in. x 46 in. x 77 in. |
Weight (w/o batteries) |
1,323 lbs. |
1,477 lbs. |
Solution (Solution / Recovery Tank) |
62 / 66 gal. |
62 / 66 gal. |
Squeegee Width |
51 in. |
51 in. |
Brush Type |
Disc |
Cylindrical |
Cleaning Path |
40 in. |
40 in. |
Brush RPM |
162 RPM |
933 RPM |
Brush/Pad Pressure |
353 lbs. max |
243 lbs. max |
Cleaning Rate |
75,347 sq. ft. per hr. |
75,347 sq. ft. per hr. |
Traction Motor |
33 A |
33 A |
Vac Motor (Dual) |
16 A |
16 A |
Brush Motor |
42 A |
42 A |
Power |
36V battery |
36V battery |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BD 32/26
Walk-Behind Automatic Scrubber |
|
Features: |
|
|
 |
|
- Large walk-behind unit suited for grocery stores, large retail facilities, schools, industrial facilities and hospitals
- 32” cleaning path
- 26 gallon solution tank
- 28 gallon recovery tank
- Simple operator interface
- Whisper Quiet 67 dB
- Built-in safety feature avoids work-related accidents
- Optional eco-friendly, 100% non-spill AGM battery available
- Heavy-duty, four-sided, parabolic squeegee
- Ergonomic handle design
- Exceptionally durable rotomolded polyethylene construction
- Stainless steel battery tray
- Manual adjustment of brush pressure
- Dual access to solution and recovery tanks
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Overview: |
|
|
|
|
BD 32/26
Walk-Behind Automatic Scrubber
Tornado’s new BD 32/26 walk-behind scrubber offers world class scrubbing, a wide cleaning path and large capacity solution and recovery tanks. This unit is perfect for use in grocery stores, retail facilities,hospitals,and warehouses.The BD 32/26 lays down cleaning solution, scrubs, then vacuums away dirty solution, leaving floors clean and dry in just one pass, even around 180 degree turns. Clean over 32,300 square feet per hour while increasing your building’s occupant health and safety. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brochure: |
|
|
|
|
|
|
|
|
|
Specifications: |
|
|
|
|
|
|
Model |
BD 32/26 |
Part Number |
99732 |
Dimensions(LxWxH) |
66 in x 29 in x 47 in 1676 mm x 737 mm x 1194 mm |
Net Weight (W/O Batteries) |
700 lbs./318 kg |
Shipping Weight |
800 lbs./ 363 kg |
Solution Tank |
26 gal. /98 I |
Recovery Tank |
28 gal. / 110 i |
Squeegee Width |
39 in / 99 mm |
Tank Construction |
Polyethylene |
Productivity (FT2 Per Hour) |
32,280 f2/hr / 2999 m2/hr |
Brush Type |
Disc |
Brush Width (2 Brushes) |
16 in / 406 mm |
Brush RPM |
190 |
Brush Pressure |
up to 133 lbs. / 60 kg |
Cleaning Path |
32 in / 813 mm |
Sound Level |
67 dB |
Vacuum Motor |
0.8 hp / 588 Watts |
Brush Motor |
1.1 hp / 809 Watts |
Battery |
24 v |
Warranty (Labor) |
1 year* |
Warranty (Batteries/Parts) |
1 yr batteries (prorated) 2 years parts |
13” Pad Holder (2 Required) |
48803030 |
Standard Rear Squeegee |
48406100 |
Standard Front Squeegee |
48403020 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Carpet Care Page 1 |
|
|
|
|
|
|
|
|
|
Carpet Care Page 2 |
|
|
|
|
|
|
|
|
|
Floor MachinesAnd Burnishers |
|
|
|
|
|
|
|
|
|
Scrubber and Dryers |
|
|
|
|
|
|
|
|
|
Specialty Products |
|
|
|
|
|
|
|
|
|
Sweepers |
|
|
|
|
|
|
|
|
|
Tank Vacuums |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Back Tornado Scrubber and Dryer |
|
|
|
|
|
Back Carpet Extractors, Floor Machiens and Vaccum |
|
|
|
|
|
Back Repquip Home |
|
|
|
|
